Overview
1-3
How Do I Read the Catalog
Number?
Knowing your catalog number for the 1336 IMPACT drive, can help
you sort out what options you have, as well as helping you
communicate this information to the Allen-Bradley support
personnel. The catalog numbers all have the following form:
1 G frame drives in enclosed construction and all H frame drives are supplied only through the Configured Drives Program.
2 D – G frame drives in IP 65 (NEMA Type 4) and IP 54 (NEMA Type 12) configurations are supplied through the Configured Drives Program.
Note: BPR indicates F frame roll-in units
1336E
First Position
Bulletin Number
mods
Sixth Position
Options
EN
Fifth Position
Language
Code
Language
EN
English/English
FR
English/French
ES
English/Spanish
DE
English/German
IT
English/Italian
PT
English/
Portuguese
AA
Fourth Position
Enclosure Type
Code
Type
AA
NEMA 1 (IP20)
AE
NEMA 1 (IP20)/
EMC
0.37–45 kW
(0.5–60 HP) only
AF
NEMA 4 (IP65)
AJ
NEMA 12 (IP54)
AN
Open (IP00)
AQ
Second Position
Voltage
Letter
Voltages
AQ
200–240VAC or 310VDC
BR
380–480VAC or 513±620VDC
CW
500–600VAC or 775VDC
A
200–240VAC
B
380–480VAC
BP
380–480VAC
(F Frame)
BX
Special Rating
C
500–600VAC
Q
310VDC
R
513–620VDC
RX
Special Rating
W 775VDC
F05
Third Position
Nominal HP Rating
Code kW
(HP)
F05
0.37 (0.5)
F07
0.56 (0.75)
F10
0.75 (1)
F15
1.2 (1.5)
F20
1.5 (2)
F30
2.2 (3)
F50
3.7 (5)
F75
5.5 (7.5)
F100
7.5 (10)
007
5.5 (7.5)
010
7.5 (10)
015
11 (15)
020
15 (20)
025
18.5 (25)
030
22 (30)
040
30 (40)
050
37 (50)
060
45 (60)
075
56 (75)
100
75 (100)
125
93 (125)
150
112 (150)
200
149 (200)
250
187 (250)
300
224 (300)
350
261 (350)
400
298 (400)
450
336 (450)
500
373 (500)
600
448 (600)
650
485 (650)
700C
522 (700)
800C
597 (800)
or
Code
Description
Human Interface Module, IP 20 (NEMA Type 1)
HAB
Blank — No functionality
HAP
Programmer Only
HA1
Programmer/Controller w/Analog Pot
HA2
Programmer/Controller w/Digital Pot
Human Interface Module, IP 65/54 (NEMA Type4/12)
HJP
Programmer Only
HJ2
Programmer/Controller w/Digital Pot
Communication Options
GM1
Single Point Remote I/O
GM2
RS–232/422/485, DF1, & DH485
GM5
DeviceNet
TM
Control Interface Options
L4
TTL Contact
L7E
TTL Contact & Encoder Feedback
L5
24VAC/DC
L8E
24VAC/DC & Encoder Feedback
L6
115VAC
L9E
115VAC & Encoder Feedback
2
1
