11-42
Parameters
129
Start/Stop Owner
You can use the lower byte of Start/Stop Owner (bits 0 through 7)
to see which SCANport device(s) are presently issuing a valid
stop command. You can use the higher byte (bits 8 through 15) to
see which SCANport device(s) are presently issuing a valid start
command. You can choose between:
0 = Stop/start input not present
1 = Stop/start input present
The bits are defined as follows:
Parameter number
File:group
Monitor Status:SCANport Status
Interface/Comm:SCANport Status
Parameter type
source
Display
bits
Factory default
not applicable
Minimum value
00000000.00000000
Maximum value
11111111.11111111
Conversion
1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit
Description
0
Stop L Opt
The L Option board owns the
stop.
1
Stop SP 1
SCANport device 1 owns the
stop.
2
Stop SP 2
SCANport device 2 owns the
stop.
3
Stop SP 3
SCANport device 3 owns the
stop.
4
Stop SP 4
SCANport device 4 owns the
stop.
5
Stop SP 5
SCANport device 5 owns the
stop.
Bit
Description
6
Stop SP 6
SCANport device 6 owns the
stop.
7
Stop P197
Logic Cmd Input (parameter 197)
owns the stop.
8
Start L Opt
The L Option owns the start.
9
Start SP 1
SCANport device 1 owns the
start.
10
Start SP 2
SCANport device 2 owns the
start.
Bit
Description
11
Start SP 3
SCANport device 3 owns the
start.
12
Start SP 4
SCANport device 4 owns the
start.
13
Start SP 5
SCANport device 5 owns the
start.
14
Start SP 6
SCANport device 6 owns the
start.
15
Start P197
Logic Cmd Input (parameter 197)
owns the start.
130
Jog1/Jog2 Owner
You can use the lower byte of Jog1/Jog2 Owner (bits 0 through 7)
to see which SCANport device(s) are presently issuing a valid
jog 2 command. You can use the higher byte (bits 8 through 15)
to see which SCANport device(s) are presently issuing a valid
jog 1 command. You can choose between:
0 = Jog 1/jog 2 input not present
1 = Jog 1/jog 2 input present
The bits are defined as follows:
Parameter number
File:group
Monitor Status:SCANport Status
Interface/Comm:SCANport Status
Parameter type
source
Display
bits
Factory default
not applicable
Minimum value
00000000.00000000
Maximum value
11111111.11111111
Conversion
1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit
Description
0
Jog2 L Opt
The L Option board owns the
Jog2.
1
Jog2 SP 1
SCANport device 1 owns the
Jog2.
2
Jog2 SP 2
SCANport device 2 owns the
Jog2.
3
Jog2 SP 3
SCANport device 3 owns the
Jog2.
4
Jog2 SP 4
SCANport device 4 owns the
Jog2.
5
Jog2 SP 5
SCANport device 5 owns the
Jog2.
Bit
Description
6
Jog2 SP 6
SCANport device 6 owns the
Jog2.
7
Jog2 P197
Logic Cmd Input (parameter 197)
owns the Jog2.
8
Jog1 L Opt
The L Option owns the Jog1.
9
Jog1 SP 1
SCANport device 1 owns the
Jog1.
10
Jog1 SP 2
SCANport device 2 owns the
Jog1.
Bit
Description
11
Jog1 SP 3
SCANport device 3 owns the
Jog1.
12
Jog1 SP 4
SCANport device 4 owns the
Jog1.
13
Jog1 SP 5
SCANport device 5 owns the
Jog1.
14
Jog1 SP 6
SCANport device 6 owns the
Jog1.
15
Jog1 P197
Logic Cmd Input (parameter 197)
owns the Jog1.
