Chapter

10

Using the Function Block

Chapter Objectives

Chapter 10 provides information for helping you to use the function
block that is included with the 1336 IMPACT drive.

What is a Function Block?

A function block is a group of parameters that work together to add
flexibility to the 1336 IMPACT drive. The function block that is
provided with the 1336 IMPACT drive lets you set up a timer delay,
state machine, multiply/divide, add/subtract, scale, an up/down
counter, or a maximum/minimum function by using a combination of
17 parameters. Because these functions use the same parameters, you
can only use one of the function blocks (such as the timer delay) in
your application.

Figure 10.1 provides an overview of the function block.

This topic:

Starts on page:

An overview of function blocks

10-1

Evaluating the inputs

10-4

Using the timer delay function

10-5

Using the state machine function

10-8

Using the add/subtract function

10-10

Using the maximum/minimum function

10-12

Using the up/down counter function

10-14

Using the multiply/divide function

10-18

Using the scale function

10-20

Using the hysteresis function

10-23

Using the band function

10-26

Using the logical add/subtract function

10-26

Using the logical multiply/divide function

10-27
