11-62 Parameters
200
Func 1 Eval Sel
1
Func 1 Eval Sel lets you choose how you want to evaluate
Function In1 (parameter 198).
1 Func 1 Eval Sel was added in Version 2.xx.
Parameter number 200
File:group Application:Prog Function
Parameter type destination
Display x
Factory default 0
Minimum value 0
Maximum value 17
Conversion 1 = 1
Refer to Chapter 10, Using the Function Block, for more
information.
Value Description
0 None
Pass the value directly on to the
function block.
1 Mask
Mask specific bits.
2 All Bits On
Check to make sure that all bits
that are set (on) in Func 1
Mask/Val (parameter 199) are set
in Function In1 (parameter 198).
3 All Bits Off
Check to make sure that all bits
that are set in Func 1 Mask/Val are
clear in Function In1.
4 Any Bit On
Check to make sure that at least
one of the bits that are set in
Func 1 Mask/Val is set in Function
In1.
5 Any Bit Off
Check to make sure that at least
one of the bits that are set in
Func 1 Mask/Val is clear in
Function In1.
Value Description
6 I=V
Check to see if Function In1 is
equal to Func 1 Mask/Val.
7 I Not = V
Check to see if Function In1 is not
equal to Func 1 Mask/Val.
8 Signed ICheck to see if the signed value of
Function In1 is less than the value
of Func 1 Mask/Val.
9 Signed I<=V
Check to see if the signed value of
Function In1 is less than or equal
to the value of Func 1 Mask/Val.
10 Signed I>V
Check to see if the signed value of
Function In1 is greater than the
value of Func 1 Mask/Val.
11 Signed I>=V
Check to see if the signed value of
Function In1 is greater than or
equal to the value of Func 1
Mask/Val.
Value Description
12 Unsign ICheck to see if the unsigned value
of Function In1 is less than the
value of Func 1 Mask/Val.
13 Unsign I<=V
Check to see if the unsigned value
of Function In1 is less than or
equal to the value of Func 1
Mask/Val.
14 Unsign I>V
Check to see if the unsigned value
of Function In1 is greater than the
value of Func 1 Mask/Val.
15 Unsign I>=V
Check to see if the unsigned value
of Function In1 is greater than or
equal to the value of Func 1
Mask/Val.
16 Invert
Pass the opposite value on to the
function block
17 Absolute
Pass a positive value on to the
function block.
201
Function In2
1
Use Function In2 to provide input into the function block that is
provided with the 1336 IMPACT drive. You can choose to either
evaluate Function In2 or pass the value directly to the function
block.
To evaluate Function In2, you need to also use Func 2 Mask/Val
(parameter 202) and Func 2 Eval Sel (parameter 203).
To pass the value directly to the function block, enter a value of 0
into Func 2 Eval Sel.
1 Function In2 was added in Version 2.xx.
Parameter number 201
File:group Application:Prog Function
Parameter type linkable destination
Conversion 1 = 1
If Func 2 Eval Sel (parameter 203) is 0 or 6 – 11, then:
Display
±x
Factory default 0
Minimum value -32767
Maximum value +32767
If Func 2 Eval Sel (parameter 203) is 1 – 5, then:
Display
bits
Factory default 00000000.00000000
Minimum value 00000000.00000000
Maximum value 11111111.11111111
If Func 2 Eval Sel (parameter 203) is 12 – 15, then:
Display
x
Factory default 0
Minimum value 0
Maximum value 65535
Refer to Chapter 10, Using the Function Block, for more
information.
