Parameters
11-39
122
Pulse In Offset
Enter the minimum speed the pulse input will go to.
Parameter number
File:group
Interface/Comm:Digital Config
Parameter type
destination
Display
±x.x rpm
Factory default
+0.0
Minimum value
-base motor speed
Maximum value
+base motor speed
Conversion
4096 = base motor speed
Refer to Chapter 7, Setting Up the Input/Output, for more
information.
123
Pulse In Value
Use Pulse In Value to view the pulse input value. You need to link
Pulse In Value to a reference parameter.
Parameter number
File:group
Interface/Comm:Digital Config
Parameter type
source
Display
±x.x rpm
Factory default
not applicable
Minimum value
0.0
Maximum value
+8 x base motor speed
Conversion
4096 = base motor speed
Refer to Chapter 7, Setting Up the Input/Output, for more
information.
124
SP Enable Mask
Use SP Enable Mask to select which SCANport devices can
control the drive. You can choose between:
0 = Disable control
1 = Enable control
Stop is always active, even if you disable a device.
The bits are defined as follows:
Parameter number
File:group
Interface/Comm:SCANport Config
Parameter type
linkable destination
Display
bits
Factory default
11111111
Minimum value
00000000
Maximum value
11111111
Conversion
1 = 1
Refer to Chapter 8, Using the SCANport Capabilities, for more
information.
Bit
Description
0
Enable L Opt
Enable the L Option board.
1
Enable SP 1
Enable SCANport device 1.
2
Enable SP 2
Enable SCANport device 2.
Bit
Description
3
Enable SP 3
Enable SCANport device 3.
4
Enable SP 4
Enable SCANport device 4.
5
Enable SP 5
Enable SCANport device 5.
Bit
Description
6
Enable SP 6
Enable SCANport device 6.
7
Enable P197
Enable Logic Cmd Input
(parameter 197).
