Page 268: 220 ncfg flt status

11-70
Parameters
217
Fstart Speed
Use Fstart Speed to set the start point at which the speed search
begins. This parameter is only active when operating in Fstart
Select mode 2 (Speed Param).
To maximize reconnect performance, always set the Fstart
Speed slightly greater than the expected reconnect motor speed.
1 Fstart Speed was added in Version 3.xx.
Parameter number
File:group
Application: Flying Start
Parameter type
linkable destination
Display
x.x RPM
Factory default
+ base motor speed rpm
Minimum value
Rev Speed Limit (Param 40)
Maximum value
Forward Speed Limit (Param 41)
Conversion
+4096 = base motor speed
Refer to Chapter 9, Applications, for more information.
218
Reserved
Leave this parameter set to 0.
Parameter number
File:group
Parameter type
Display
Factory default
Minimum value
Maximum value
Conversion
219
PwrUp Flt Status
PwrUp Flt Status indicates that a fault condition has been
detected during power up or reset of the drive. When a bit is “1”,
the condition is true; otherwise, the condition is false.
1 PwrUp Flt Status was added in Version 3.xx.
Parameter number
File:group
Monitor: Fault Status
Parameter type
source
Display
Bits
Factory default
0000 0000 0000 0000
Minimum value
0000 0000 0000 0000
Maximum value
1111 1111 1111 1111
Conversion
1 = 1
Bit
Condition
0
CP EPROM
1
CP Int RAM
2
CP Ext RAM
3
CP Stack Ram
4
CP MBI
5
Reserved
Bit
Condition
6
Reserved
7
Reserved
8
VP EPROM
9
VP Int Ram
10
VP Ext Ram
11
VP Stack RAM
Bit
Condition
12
VP MBI
13
Reserved
14
EE Checksum
15
EE R/W
220
Ncfg Flt Status indicates that a fault condition in the drive
CANNOT be configured as a warning. When a bit is “1”, the
condition is true; otherwise, the condition is false. Bits 0 – 3 are
detected by hardware. Bits 4 – 15 are detected are detected by
software.
1 Ncfg Flt Status was added in Version 3.xx.
Parameter number
File:group
Monitor: Fault Status
Parameter type
source
Display
Bits
Factory default
0000 0000 0000 0000
Minimum value
0000 0000 0000 0000
Maximum value
1111 1111 1111 1111
Conversion
1 = 1
Bit
Condition
0
Bus Overvolt
1
Trans Desat
2
Ground Flt
3
IOC
4
VP Handshake
5
Diff SW Ver
Bit
Condition
6
Dr Type Dif
7
III Drv Type
8
CP Handshake
9
Abs overspd
10
+/- 15v Tol
11
Auto/Diag
Bit
Condition
12
Inv Temp Trp
13
Task Overrun
14
Ill Interrupt
15
Mode Timeout
