Parameters
11-21
46
Droop Percent
Use Droop Percent to specify the percent of base speed that the
speed reference is reduced when at full load torque. You can use
this feature to cause motor speed to droop with an increase in
load.
Parameter number
File:group
Control:Speed Regulator
Parameter type
linkable destination
Display
x.x%
Factory default
0.0%
Minimum value
0.0%
Maximum value
25.5%
Conversion
10 = 1.0
47
S-Curve Percent
Use S-Curve Percent to create an adjustable S curve ramp.
S-Curve Percent controls the level of filtering that is applied to the
output of the acceleration and deceleration ramp.
1 S-Curve Percent was added in Version 2.xx.
Parameter number
File:group
Control:Accel/Decel
Parameter type
linkable destination
Display
x.x%
Factory default
0.0%
Minimum value
0.0%
Maximum value
100.0%
Conversion
10 = 1.0%
Refer to the Speed Reference Selection Overview in Appendix B,
Control Block Diagrams, for more information.
If S-Curve Percent is
set to:
Then the S-Curve is:
0
Not used.
50%
Applied for half of the ramp time.
100%
Applied for the entire ramp.
48
PTrim Output
PTrim Output represents the scaled and limited output of the
process trim function. You can use PTrim Output as a parameter
source or to offset the speed or torque reference. To offset the
speed or torque reference, you need to select either bit 0 or bit 1
in PTrim Select (parameter 51).
Parameter number
File:group
Application:Process Trim
Parameter type
source
Display
±x.x%
Factory default
not applicable
Minimum value
-800.0%
Maximum value
+800.0%
Conversion
4096 = 100.0%
Refer to the Trim Control Overview section in Appendix B,
Control Block Diagrams, for more information.
49
PTrim Reference
PTrim Reference is the reference input value for process trim.
PTrim Reference and PTrim Feedback (parameter 50) are
compared and used to update PTrim Output (parameter 48).
Parameter number
File:group
Application:Process Trim
Parameter type
linkable destination
Display
±x.x%
Factory default
+0.0%
Minimum value
-800.0%
Maximum value
+800.0%
Conversion
4096 = 100.0%
Refer to the Trim Control Overview section in Appendix B,
Control Block Diagrams, for more information.
50
PTrim Feedback
PTrim Feedback is the feedback input value for process trim.
PTrim Feedback and PTrim Reference (parameter 49) are
compared and used to update PTrim Output (parameter 48).
Parameter number
File:group
Application:Process Trim
Parameter type
linkable destination
Display
±x.x%
Factory default
+0.0%
Minimum value
-800.0%
Maximum value
+800.0%
Conversion
4096 = 100.0%
Refer to the Trim Control Overview section in Appendix B,
Control Block Diagrams, for more information.
