Getting started
ETC PLC programming with CoDeSys
Configuring the control system in the ETC−CoDeSys
2
2.11
2.11.2
l
52 EDSTCXN EN 2.0
1. Start the ETC−CoDeSys via W Programs W Lenze W CoDeSys.
2. If required, you can change the language in the CoDeSys:
– Projekt W Optionen W Arbeitsbereich W Sprache = englisch
– Project W Options W Desktop W Language = german
3. Create a new project via File W New.
4. In the "Target system settings" dialogue, select the respective control
system.
5. Accept the default setting.
A dialogue for the first block is displayed. The name can be freely selected
(e.g. PLC_PRG). As a first block, a program in the language ST (structured
text) is created in the default setting.
ETCM019
6. Press
7. Save the new file via File W Save.
ETCM020
Start ETC−CoDeSys and create
new project
