ETC−MMI
"Programming" operating mode
ASCI editor
7
7.6
7.6.1
l
307 EDSTCXN EN 2.0
1. Select the file whose profile you want to display (see above).
2. Afterwards, press the key several times until the "Kontur des
Programms anzeigen" ("Display profile of the program") button is
selected.
3. Finally, press .
The profile of the selected program is displayed.
4. Press to close the display.
By means of the display filter, the display of the files in the "File selection
field" can be extended or limited.
The display filter is shown in addition to the directories in square brackets
[*.DIN]. When this entry is selected, all data of the current directory affected
by this filter is transferred to the control system.
Display profile of the program
Set filter
