6.5 Communication values in the DPR area
Name Meaning
Communication area MMI−>NC
mmi2t_order_us Command to the communication processor
t2mmi_quitt_us Acknowledgement from the communication processor
t2mmi_status_us Status from the communication processor
mmi2t_quitt_us Acknowledgement to the communication processor
msq2nc_r.qc_uc Message acknowledgement counter
msq2nc_r.mc1_us Messages−Start−Message counter
msq2nc_r.sb0_us Messages−Main group
msq2nc_r.sb1_us Messages−subgroup
msq2nc_r.mc2_us Messages−End−Message counter
Communication area NC−> MMI
nc2t_order_us Command to the communication processor
t2nc_quitt_us Acknowledgement from the communication processor
t2nc_status_us Status from the communication processor
nc2t_quitt_us Acknowledgement to the communication processor
msq2mmi_r.qc_uc Message acknowledgement counter
msq2mmi_r.mc1_us Messages−Start−Message counter
msq2mmi_r.sb0_us Messages−Main group
msq2mmi_r.sb1_us Messages−subgroup
msq2mmi_r.mc2_us Messages−End−Message counter
