ETC−MMI
"Setup" operating mode
7
7.4
l
296 EDSTCXN EN 2.0
ETCN070
Import + save The data from the table is transferred to the NC
computer and saved on the PC in a file.
back... Back to the previous level.
Load tool record Open a dialogue for selecting a file with tool data (WTK
file). This file will be transferred to the control system.
Tool number In the upper edge of the "Status displays" dialogue
there is a field for entering a tool number (Tx). After the
key has been pressed, the field has a coloured
background and the cursor flashes in this field. A tool
number can be entered here. Changes are adopted with
and discarded with .
back... Back to the previous level.
Enter M function In the upper edge of the "Status displays" dialogue
there is a field for entering an M function. After the key
has been pressed, the field has a coloured background
and the cursor flashes in this field. A function number
can be entered here. Changes are adopted with
and discarded with .The M function is transferred
to the PLC for execution.
Entry Enter single block (e.g. G, S, T and M functions). The
execution is completed and triggered with .
Start Trigger action (e.g. automatic home position approach).
Stop Quit all axis movements and a running program.
Travel+ Manual traverse key for positive axis direction of the
selected axis.
Travel− Manual traverse key for negative axis direction of the
selected axis.
Axis Select the axis to be traversed. Alternatively, the axis
can be selected by means of the keys.
Override+ Increase the axis or path speed of the selected axis (in
percent of MK_VMAX). Over 10%, the value is changed
in steps of 10%, below 10% in steps of 1%.
Override− Reduce the axis or path speed of the selected axis (in
percent of MK_VMAX). Over 10%, the value is changed
in steps of 10%, below 10% in steps of 1%.
Vertical function keys
