PLC programming
Interface to the ETC
System variables of the ETCxC
8
8.7
8.7.2
l
357 EDSTCXN EN 2.0
DB1_sps2nc_programmstop_b %MB1.12.0
DB1_sps2nc_unterbrechen_bit %MX1.12.8
DB1_sps2nc_einzel_folgesatz_bit %MX1.13.0
DB1_sps2nc_satzausblenden_bit %MX1.13.8
DB1_sps2nc_rueckzug_bit %MX1.14.0
DB1_sps2nc_tastensignale_aw %MW1.16 ARRAY[0..1] OF WORD
DB1_sps2nc_qbit_signale_aw %MW1.18 ARRAY[0..3] OF WORD
DB1_sps2nc_freigaben_mmi_w %MW1.31
DB1_sps2nc_mfkt_quitt_bit %MX1.32.0
DB1_sps2nc_sfkt_quitt_bit %MX1.33.0
DB1_sps2nc_hfkt_quitt_bit %MX1.33.0
DB1_sps2nc_tfkt_quitt_bit %MX1.34.0
DB1_sps2nc_extsync_enable_bit %MX1.35.0
DB1_sps2nc_programmhalt_aktiv_bit %MX1.35.8
DB1_sps2nc_qin_mask_aw %MW1.36 ARRAY[0..1] OF WORD
DB1_sps2nc_qout_mask_aw %MW1.38 ARRAY[0..1] OF WORD
DB1_sps2nc_qout_akt_aw %MW1.40 ARRAY[0..1] OF WORD
DB1_sps2nc_qin_offset_ab %MW1.42 ARRAY[0..1] OF BYTE
DB1_sps2nc_qout_offset_ab %MW1.43 ARRAY[0..1] OF BYTE
DB1_sps2nc_spsoverride_allg_w %MW1.80
DB1_sps2nc_spsoverride_spindel_w %MW1.81
DB1_sps2nc_spsoverride_ozillation_w %MW1.82
DB1_sps2nc_spsoverride_sps_w %MW1.83
DB1_sps2nc_verfahr_ab %MB1.84.0 ARRAY[0..11] OF BYTE
DB1_nc2sps_betriebsbereit_1_bit %MX1.128.0
DB1_nc2sps_betriebsbereit_2_bit %MX1.128.1
DB1_nc2sps_referenzpunkt_w %MW1.129
DB1_nc2sps_referenzfahrt_laeuft_w %MW1.130
DB1_nc2sps_betriebsart_w %MW1.131
DB1_nc2sps_nc_programm_laeuft_bit %MX1.132.0
DB1_nc2sps_nc_programm_laeuft_1_bit %MX1.132.1
DB1_nc2sps_satzvorlauf_aktiv_bit %MX1.132.2
DB1_nc2sps_einzelsatz_laeuft_bit: %MX1.132.3
DB1_nc2sps_unterbrechen_aktiv_bit %MX1.132.4
DB1_nc2sps_alle_achsen_stehen_bit %MX1.132.8
DB1_nc2sps_wahlweise_halt_b %MB1.133.0
DB1_nc2sps_programmstartzaehler_b %MB1.133.1
DB1_nc2sps_achse_faehrt_w %MW1.134
DB1_nc2sps_modal_am_ziel_w %MW1.135
DB1_nc2sps_spindel_aktiv_w %MW1.136
DB1_nc2sps_programmstart_b %MB1.137.0
DB1_nc2sps_canmodul_vorhanden_w %MW1.138
DB1_nc2sps_can_status_w %MW1.139
DB1_nc2sps_programmstop_b %MB1.142.0
DB1_nc2sps_vorschub_halt_b %MB1.144.0
DB1_nc2sps_mfkt_strobe_bit %MX1.150.0
DB1_nc2sps_mfkt_w %MW1.151
DB1_nc2sps_hfkt_strobe_bit %MX1.159.0
DB1_nc2sps_hfkt_w %MW1.160
