Interface PLC <˘> NC operating system
Definitions
Data block 1
5
5.1
5.1.2
l
262 EDSTCXN EN 2.0
0 Start of the NC program entered in the P field (512)
1 Start of the NC program entered in the P field (514)
2 Start of the NC program entered in the P field (516)
3 Start of the NC program entered in the P field (518)
4 Start of the NC program entered in the P field (520)
5 Start of the NC program entered in the P field (522)
6 Start of the NC program entered in the P field (524)
7 Start of the NC program entered in the P field (526)
8
9
10
11
12
13
14
15 Start of the automatic home position approach
0 No response
1 Start (normal procedure)
2 Start block search (P528−P532 configuration of the entry point)
3
4
5
6
7
8
9
10
11 Resumption of a program which was interrupted by an error at a defined point (G10)
12 Resumption of an interrupted program after normal operation has been resumed
(implicitly)
13 Resumption of a program which has been interrupted by an error without any previous
correction measures
14 Start after M0/M1
15 Start of the next block in individual operation
Effect in the PLC: Checking the start prerequisites for the respective start
mode and, if required, enable of the program start by setting the "Pro-
grammstart" ("Program start") signal (DW 009). Output of a corresponding
error message if the start is denied.
Values of the nibble with the
higher value
Values of the nibble with the
lower value
