PLC programming
Library
MMI communication functions
8
8.8
8.8.7
l
415 EDSTCXN EN 2.0
If a message from HMI is available when calling GetApplicationMessage, OK
is set to TRUE and the message copied into the defined buffer. The function
provides an immediate return in any case, even if no message from HMI is
available. In that case OK is set to FALSE.
By evaluating sb1_b the message can be identified by the PLC. The definition
of control blocks must take place between the PLC and MMI developer. The
length of the user data is stored in len_w in bytes.
The variables sb2_b and index_b are optional. Their use must be resolved
between the PLC and HMI developer. handle_b is reserved for the
simultaneous communication with several applications.
)
Note!
These messages are always transferred unsynchronised. Up to 10
messages of this type form MMI to PLC can be buffered in the
control, the rest will be lost. In this case the control reports a
corresponding error message. If necessary, synchronisation
mechanisms must be agreed between HMI and PLC.
8.8.7.2 PutApplicationMessage
FUNCTION_BLOCK PutApplicationMessage (* sends a message with up to 512 Byte user
data to the MMI *)
VAR_INPUT
data_pab : POINTER TO ARRAY[0..511] OF BYTE;
Datatypes_s : STRING(255);
sb1_b : BYTE;
sb2_b : BYTE;
index_b : BYTE;
handle_b : BYTE;
len_w : WORD;
END_VAR
VAR_INPUT
ok : BOOL;
END_VAR
data_pab Pointer to user data to be sent
Datatypes_s Optional data descriptor, see DefDataTypes
sb1_b Control block 1 of the message to HMI
sb2_b Control block 2, optional
index_b Block counter, optional
handle_b Receiver ID, reserved
len_w Length of received user data in bytes
ok TRUE, if a message has been sent
Declaration
Parameters
