ETC−MMI

"Automatic" operating mode

7.5

299

EDSTCXN EN 2.0

Start program number

Enter the program number of the program to be edited.
Before, the program must be transferred via the
"Program to NC" function (if required, with all necessary
subprograms). The program is started via the
key.

Program to NC

Transfer program from the PC to the ETCxC. After a
function has been called, a dialogue is displayed. Via the
keys, select a program and start the transfer
with . cancels the action.
Note: In the "DelphMMi.ini", you can determine which
programs are loaded automatically when the control
system is initialised (

^ 327).

Online program

Use this function for programs which are too big to be
transferred to the NC as a whole. A dialogue opens
(

^ 306). Here you can selected the desired program.

After has been pressed, the program is
transferred to the ETCxC block by block. With ,
the program is started without having to be transferred
completely. The output line shows the selected program
and the part (in percent) that has already been
transferred.
If the text "WAIT" is displayed behind the percentage,
the memory in the ETCxC can no longer accept any data
at the moment. After the transferred block has been
processed, the next block is automatically transferred
until the program has been completely processed.
When editing a program "online", please note that the
program must not contain any jumps and branches. For
subprograms or cycle calls, the program must be loaded
in the ETCxC first.

Online cancel

Quit online mode. After a restart, processing must be
started anew.

Optionally stop on/off

Stop the program with a "M1" command. The program
is continued with . M1 must be edited
accordingly by the PLC.

Block suppression on/off

Do not execute all blocks marked with a "/".

Single follow−up block

Each traverse block must be triggered by the
key. In the case of a switch−over during running
operation, processing is stopped with the next possible
block. After the "Single block" function has been
deactivated, the key must be pressed again.

Graphics...

Graphics on/off

Show a graphical display of the current program instead
of the position display.
The graph is currently limited to a profile description of
the axes X and Y. Zero shift, rotation, individual
programming and similar are not supported.

Horizontal function keys
