Getting started
Establishing the communication between PC and ETCHx
Starting the terminal program "HyperTerminal" and activating the monitor interface
2
2.4
2.4.2
l
24 EDSTCXN EN 2.0
Command Meaning
dir [dr:][pattern] Shows the contents of the specified drive. The flashdisk (sd:) is preset, other
possible drives are program storage (ps:), Ram disk (rd:) and floppy disk
(fd:), if existing. As pattern, the usual MS−DOS patterns can be used, e.g.:
*.din
del [dr:][pattern] Deletes the specified files on the specified drive. The flash disk (sd:) is
preset.
cd [dr:] Changes to or shows the currently selected drive. The flash disk (sd:) is
preset.
format dr: Formats the current disk and thus deletes all files on this disk. A disk name
must be specified.
reboot Resets the control system. To activate the boot monitor, the "!" key must be
pressed afterwards until the boot monitor responds (this may take
3−4 seconds).
help Displays the help page with commands of the monitor program.
ver Displays version string
ipconf Configures network parameters for Ethernet interface
hwconf Displays hardware configuration of the control system (CPU type, memory
etc.)
If you cannot establish a connection to the ETCHx by means of the described
procedure, proceed as follows:
1. Check the cabling between PC and ETCHx.
2. Check the connection parameters of the terminal program.
A first test of the cable connection can be performed by means of a bridge
between the pins 2 and 3 at the socket of the cable (control system side):
ƒ Afterwards, the terminal program is called as usual and any letters can
be entered via the keyboard.
ƒ If the entered characters of the keyboard are correctly displayed in the
mask of the terminal program (the characters are sent back by the
bridge as echo), the cable must be checked for exchanged pins (pin2/3),
for short circuit and the connection must be checked for correct
parameter setting.
Important commands of the
monitor program
Fault elimination
