PLC programming
Interface to the ETC
System variables of the ETCxC
8
8.7
8.7.2
l
358 EDSTCXN EN 2.0
DB1_nc2sps_sfkt_strobe_bit %MX1.159.0
DB1_nc2sps_sfkt_w %MW1.160
DB1_nc2sps_tfkt_strobe_bit %MX1.168.0
DB1_nc2sps_tfkt_w %MW1.169
DB1_nc2sps_refpunkt_angefahren_w %MW1.177
DB1_nc2sps_endschalter_plus_w %MW1.178
DB1_nc2sps_endschalter_minus_w %MW1.179
DB1_nc2sps_referenznocken_w %MW1.180
DB1_nc2sps_reserveeingang_w %MW1.181
DB1_nc2sps_slave_endschalter_plus_w %MW1.182
DB1_nc2sps_slave_endschalter_minus_w %MW1.183
DB1_nc2sps_slave_referenznocken_w %MW1.184
DB1_nc2sps_slave_reserveeingang_w %MW1.185
DB1_nc2sps_copmodul_vorhanden_aw %MW1.192 ARRAY[0..7] OF WORD
DB1_nc2sps_spsoverride_allg_w %MW1.200
DB1_nc2sps_spsoverride_spindel_w %MW1.201
DB1_nc2sps_spsoverride_ozillation_w %MW1.202
DB1_nc2sps_spsoverride_sps_w %MW1.203
DB1_nc2sps_verfahr_ab %MB1.204.0 ARRAY[0..11] OF BYTE
DB1_nc2sps_mmi_tasten_aw %MW1.212 ARRAY[0..7] OF WORD
DB2_sps2mmi_zustand_aw %MW2.0 ARRAY[0..15] OF WORD
DB2_sps2mmi_anzeige_aw %MW2.16 ARRAY[0..63] OF WORD
DB2_sps2mmi_hinweis_aw %MW2.80 ARRAY[0..15] OF WORD
DB2_sps2mmi_quit_cnt_w %MW2.96
DB2_sps2mmi_msg_cnt1_w %MW2.97
DB2_sps2mmi_msg_auftrag_w %MW2.98
DB2_sps2mmi_msg_laenge_w %MW2.99
DB2_sps2mmi_msg_daten_aw %MW2.100 ARRAY[0..25] OF WORD
DB2_sps2mmi_msg_cnt2_w %MW2.126
DB2_sps2mmi_ok_cnt_w %MW2.127
DB2_mmi2sps_zustand_aw %MW2.128 ARRAY[0..15] OF WORD
DB2_mmi2sps_tasten_aw %MW2.144 ARRAY[0..15] OF WORD
DB2_mmi2sps_quit_cnt_w %MW2.160
DB2_mmi2sps_msg_cnt1_w %MW2.161
DB2_mmi2sps_msg_auftrag_w %MW2.162
DB2_mmi2sps_msg_laenge_w %MW2.163
DB2_mmi2sps_msg_daten_aw %MW2.164 ARRAY[0..25] OF WORD
DB2_mmi2sps_msg_cnt2_w %MW2.190
DB2_mmi2sps_ok_cnt_w %MW2.191
DB2_nc2sps_technodaten_aw %MW2.192 ARRAY[0..31] OF WORD
DB2_nc2sps_maschinenkonstante_aw %MW2.224 ARRAY[0..31] OF WORD
DB13_nc2mmi_achskennung_ab %MW13.12 ARRAY[0..15] OF BYTE
Data block 2
Data block 13
