4.3 Software configuration
4.3.1 MK_KUNDE
This machine constant is a string constant by means of which the different
customer−specific extensions are activated within the control. This includes
technology−specific correction modules and M function handler.
Value Meaning
"" Standard TRC, no special treatment of M functions (default).
"SCHNEIDEN"
(CUT)
TRC with tangential correction of the C axis for cutting technology, special
treatment for M14, M15, M16 und M1014, M1015, M1016.
"SCHNEIDEN1"
(CUT1)
Like "SCHNEIDEN" (CUT), but with additional functions for the
management of the knife length at the beginning and the end of the
profile, additional special treatment for M46, M47, M50, M51 and M1046,
M1047, M1050, M1051.
"SCHNEIDEN2"
(CUT2)
TRC compatibility mode with tangential correction of the C axis for cutting
technology without special treatment of M functions.
"SCHNEIDEN3"
(CUT3)
Like "SCHNEIDEN2" (CUT2), but an additional rectangular approach or
withdrawal block is inserted for G41/42 or G40.
... Customer−specific modules that cannot be listed here.
4.3.2 MK_VOREINSTELLUNG
This machine constant is a string constant via which several default settings
of G functions can be implemented. The following G functions may be
specified within the string separated by a semicolon:
Value Meaning
G0−G3
G100−G103
Set modal G function, optionally with speed specification F
Example: AG1 F1000
G17 / G18 / G19 Selection of main plane X−Y / Z−X / Y−Z
G26 Activation of software limit switch of the specified axes, example: AG26 X0
Y0
G30 / G31 Activation of route operation / path operation
G60 Activation of Look Ahead or exact positioning, example: AG60 X0
G90 / G91 Activation of absolute dimension / incremental dimension for all axes
G112 Activation of tangential correction of the specified axis (A,B,C,a,b,c),
example: AG112 C1
G122 Configuration of traverse button operation, example: AG122 X1
The specified string must be specified in inverted commas and must not
exceed 80 characters. The configured default settings are automatically
activated when the control is started up after the MCs have been loaded as
well as at the program end and after a program termination.
MK_VOREINSTELLUNG "G17; G1 F30000; G26 X0 Z0";
For further information on the G functions, refer to chapter "CNC
programming".
Example
