Trigger - Overview

Removing a condition

Use the

and

buttons to select the condition to be removed and press the

button on the Condition con-

figuration pane.

Changing the condition order

To change the order in which conditions are tested, use the

and

buttons on the Condition configuration

pane.

Actions

Every trigger needs an action, the thing to do, which you can drag from the directory onto the Action field of the

trigger or press the

button on the Action configuration pane and use the pull-down menu to select the required

type, see

basic

advanced

and Remote Device actions.

Up to 32 actions can be applied to each trigger in this way and you can use the

and

buttons to select each

one for configuration.

Configuring an action

Type - the action type

Controller - the controller that will process the action

Parameters - the data required for each action type, varies by type so refer to the appropriate action
descriptions

Removing an action

Use the

and

buttons to select the action to be removed and press the

button on the Action configuration

pane.

Changing the action order

To change the order in which actions are executed, use the

and

buttons on the Action configuration pane.

Copying a trigger

Select the trigger to be copied in the management area and use right-click > Copy to create a copy in the row
immediately below, very useful for defining similar triggers since all the defined conditions and actions are also
copied.

Deleting a trigger

Select the trigger in the management area and use right-click > Delete or press the

button on the Trigger con-

figuration pane, the entire trigger, its conditions and actions will be deleted.
