Unison Mosaic Designer User Manual
Set Timecode
Use this to set the timecode position for one of the six Time Sources (set the appropriate timecode format).
Set Fixture RGB
Use this to inhibit a fixture's RGB levels selectively either to a fixed value or to track a variable. The latter makes
for some very interesting realtime effects when used in conjunction with 2D and Media presets. Set a fade time to
introduce the change.
Clear Fixture RGB
Use this to clear one or all fixture RGB inhibitions (see above), set a fade time to release the change(s).
Set DALI Level
Use this to set an intensity level on DALI fixtures patched to a specified Interface. You can specify whether you
want all of the fixtures on that Interface, fixtures in a certain group or a single fixture to be affected by the level
change. You can also specify a fade time or choose to reuse the last fade time stored on the ballasts.
Recall DALI Scene
Use this to a DALI scene on DALI fixtures patched to a specified Interface. You can specify whether you want all
of the fixtures on that Interface, fixtures in a certain group or a single fixture to be affected by the scene change.
You can also specify a fade time or choose to reuse the last fade time stored on the ballasts.
DALI Command
Use this to send a DALI command to DALI fixtures patched to a specified Interface. You can specify whether you
want all of the fixtures on that Interface, fixtures in a certain group or a single fixture to be affected by the com-
mand. DALI commands include off, fade up/down, step up/down, step to min/max, step down and off and step up
and on. Where fading is involved, you can specify a fade rate or choose to reuse the last fade rate stored on the
ballasts.
Mark DALI Ballast Fixed
Use this to mark all or a single emergency ballast as fixed on the specified interface.
DALI Start Emergency Test
Use this to start a Duration or Function test on all or a single DALI address(es) on the specified interface.
DALI Stop Emergency Test
Use this to stop a Duration or Function test on all or a single DALI address(es) on the specified interface.
