Unison Mosaic Designer User Manual
Mac OS X users:
Pressing the File Transfer button in the Network pane will launch an FTP client on Mac OS X. By default, this cli-
ent is Finder, and Finder doesn't allow write access to FTP servers. In order to send files to a Controller from Mac
OS X, you will need to install another FTP client. We recommend Cyberduck
which is free.
When you first run Cyberduck, you should be prompted to make it the default FTP client. You should choose to
do this. If you are not prompted, or Cyberduck is not used as the FTP client when attempting to perform a file
transfer to a Controller, go to the Preferences in Cyberduck and under the FTP tab, there is a 'Default Protocol
Handler' option. Set this to Cyberduck.
Controller status
The fields in the controller spreadsheet provide status information:
Number
The unique identifier given to each Controller in the project
Name
The user name given to each Controller in the project, typically a name that identifies the
Controller's purpose or location
Time Server
"Yes" indicates that this Controller set as the Time Server
Type
The type of Controller
Serial Number
The Controller's serial number as found on the base of the Controller
IP Address
If connected via Ethernet the Controller's IP address which is either statically assigned or
obtained from a DHCP server
USB
"Yes" indicates that the Controller is connected via USB
Firmware
The Controller's firmware version which must match that of Designer
Bootloader
The Controller's bootloader version
Memory Card Size
The size of the Controller's memory card, this can be user upgraded if required
Show Name
The name of the project that has been uploaded
Watchdog
"Yes" indicates that the Controller's watchdog is turned on
Used Channels
The number of used channels on the Controller
Capacity
The number of available (unused) channels on the Controller
Joined
"Yes" indicates that the Controller has joined the Designer session because it has been
associated and the project files match
Output Live
Check this box (the default) if you want the Controller to participate in Output Live (see
below)
Disabling Output Live
While all the other columns give status feedback, the Output Live cell is editable and allows you to stop a Con-
troller from participating in
. This is useful for soft openings where you may have multiple Controllers
in various geographical zones, some of which are open to the public and so need to be protected from your pro-
gramming and testing efforts in another zone. Uncheck this box to disable.
