File formats
File formats
Fixture plan file format (*.csv)
The fixture plan file format is versioned to ensure that CSV files generated for Designer 1.7.x and later will be
imported into any version of Designer from 1.7.0 onwards. Version information must be added to the first line of
the CSV file as follows:
#version=2
The current version is 2.
Lines starting with # are comments and are ignored (except the version line). Blank lines are ignored.
Fixture type syntax
@[manufacturer id],[model id](,[mode id])
where [manufacturer id] and [model id] are the numbers which can be found in the fixture's identification fields in
Setup. [mode id] is optional, leaving it out assumes mode 0 or that it is irrelevant.
l
The fixture type must be specified before any fixture position line(s)
l
Multiple fixture type lines can appear consecutively in a file for batches of different fixture types
Fixture position syntax
[fixture number],[name],[x position],[y position],[rotation angle],[width],[height],[comment 1],[comment 2]
where [fixture number], [x position], [y position], [rotation angle], [width] and [height] are mandatory numbers and
[name], [comment 1] and [comment 2] are strings which may be left blank. [rotation angle] is specified in
degrees, clockwise from vertical.
l
Fixture position lines must be specified after a fixture type line
l
Fixture numbers must be unique in the file and must not already exist in the project
l
The plan will be resized to accommodate the fixture positions, after getting confirmation that it is alright to
do so
Example
# LEDs
@0,5
1,,0,0,0,50,50
2,,30,0,0,50,50
3,,60,0,0,50,50
4,,90,0,0,50,50
# Dimmers
@0,0
100,,100,100,0,25,25
