Network - Controller protocols
Network - Controller protocols
With a Controller selected, choose the Protocols tab which is also available from the Patch window:
Depending on the Controller type selected, the Protocols tab allows you to configure the available eDMX and
other output protocols:
Network 2 (Protocol)
TPC, revised MSC 1, 2 & 4
Though the TPC and MSC 1, 2 & 4 (revised hardware) only have a single Ethernet port, this port may be con-
figured with two IP addresses - one for management data and the other for output protocol data. The default set-
ting is for this dual IP mode to be disabled, so that the same IP settings are used for management and output
protocol data. Dual IP mode is particularly useful for working with KiNet power supplies, which must use
10.xx.xx.xx addresses.
MSC X
The MSC X has a dedicated Ethernet Protocol port. The default setting is to obtain IP settings via DHCP but
static IP settings can alternatively be set as required.
