To create a group – ETC Unison Mosaic Designer v1.11.0 User Manual
Page 39
Selecting fixtures
Finally, Groups can be used to set up intensity control zones in the
window.
To create a group:
1. Select the fixtures you want to group using the Browser, the Plan or both - the order you do this in determ-
ines the order within the group
2. Right-click a member and choose Create Group From Selection or press the New Group button at the top
of the Browser
3. Name the group which has been created in the Browser containing those fixtures
Alternatively:
1. Press New Group with no fixtures selected
2. Name this empty group
3. Drag fixture/pixel selections into the group from within the Browser - the order you do this in determines
the order within the group
- 39 -
