Network - Controller properties
Network - Controller properties
With a Controller selected, choose the Controller Properties tab:
Identification
Use these fields to identify a project Controller with a name and type, then associate it with a real Controller and
set the Time Server, see
Controller Association .
Screen
TPC
User interfaces for the TPC are created using the companion Touch Editor application, which is available to down-
load from our website. Browse to the Touch Editor project file to associate it with the selected TPC. Changes to
the Touch Editor project file will automatically be detected. To remove the current Touch Editor project file, click
the clear button.
Set the backlight brightness for normal operation and for when the TPC has been inactive for a period of time. The
inactivity time is also set here, along with the time before the screen turns off completely.
