ETC Unison Mosaic Designer v1.11.0 - Manual (Page 182)

Unison Mosaic Designer User Manual
Controller '?' doesn't have a valid IP address for Network 2
Reconfigure the Protocol port to use a valid IP
address
Controller '?' doesn't have a interface file for the screen
The TPC in the project doesn't have an associated
Touch Editor file, see
Controller Properties
Controller '?' (TPC) has been configured with a TPC-RIO
but there is no TPC-RIO discovered
Connect the Controller to a TPC-RIO or uncheck the
'Configure TPC-RIO' checkbox in
Controller Inter-
faces .
Controller '?' (TPC) has patch for DMX 1 but has not been
configured with a TPC-RIO or proxy MSC
Connect the Controller to a TPC-RIO or MSC 1 for
DMX output. Alternatively remove DMX patch from
the controller.
- 182 -
