Triggers - Variables
DALI Input
If the trigger is using a Min to Max range then the matching number will be stored as variable 1.
DALI Ballast Error
If All is selected instead of a specific address then the address of the ballast reporting the error will be stored as
variable 1.
BPS Button
If the button number is set to Any, the trigger captures the pressed button as variable 1.
Alternatively, if the BPS station number is set to Any, then the station number is captured as variable 1 and the
button number as variable 2.
Paradigm Indicator
If any of the parameters are set to Any then they will be captured as variables. The variable index order will follow
the order that the parameters are displayed in the trigger.
Conditions that capture variables
Digital Word
This condition will capture a variable from the inputs set to match either value. This variable will be added on the
end of any variables captured by the trigger.
Conditions that use variables
DALI Ballast Error
The DALI ballast address on a specific interface can be passed in by variable. Select the relevant "Variable"
option and then choose the variable index.
Actions that use variables
Captured variables can then be used in actions by specifying the variable index (corresponding to the order in
which the variables were captured). If you have multiple actions associated with a trigger then each action can
use the variables independently.
Start, Release, Toggle, Resume and Pause Timeline
Rather than selecting a timeline as a property of the action you can specify the timeline number in a variable. This
is a very powerful feature when you want an external system to be able to call up any one of a large number of
timelines because you do not need to define separate triggers for each timeline.
