DALI
3. Select which ballasts are to be a member by double-clicking the ballast's cell
The DALI group is added to the Browser and group configuration data ready to be uploaded into the ballasts.
To delete a DALI group:
1. Right-click on the group in the Browser
2. Select Delete
3. Press Ok to confirm
The DALI group is removed and the group configuration data updated ready to be uploaded into the ballasts.
If groups have already been programmed onto the DALI fixtures you can press the Discover Groups button to
automatically populate group information from the fixtures on the interface.
DALI scenes
In Designer's implementation, DALI scenes are common across DALI interfaces, use the pull-down on the DALI
toolbar and select Scene Setup for programming:
The Browser and project plan are displayed so that you can select the DALI fixtures and groups. On the right are
the DALI scenes folder and the Intensity controls.
There can be up to 16 DALI scenes which can contain programming for some or all of your DALI fixtures, even if
spanning different DALI interfaces. In general you should include programming for all your DALI fixtures in each
scene since you can determine when creating timelines which fixtures or groups should run the scene by drop-
ping the DALI scene on the appropriate timeline row, the choice is yours though.
