Program - Timeline Properties
Working with audio
By selecting one of the four Audio Buses, the properties pane will give further options:
Band
The Audio Expansion Module generates five frequency bands (63Hz, 250Hz, 1KHz, 3.5KHz and 12KHz) and the
RIO A can generate up to 30 frequency bands (configured in
). Use this pull-down to
select which band will drive the timeline.
Audio Buses
The four Audio Buses are internal buses to which one patches the external audio sources available to the system
via one or more RIO As or Audio Expansion Modules. You can use the Audio Feedback window available from
the View menu to monitor each Audio Bus:
