Network - Controller association
Network - Controller association
It is here that you connect your project programming in Designer with real, networked Unison Mosaic Controllers:
Project vs real Controllers
The list of Controllers is split into two sections: At the top is the list of project Controllers which may or may not
be associated with real Controllers. Underneath is a list of all the unused real Controllers found on the network
that have not been associated with project Controllers.
When you create a new Designer project a single MSC with 2 output universes is added to get you started. These
project Controllers are purely virtual and so must be associated with a real Controller on the network before you
can
or
IMPORTANT: You can only associate a Controller running the same firmware as Designer - Controllers running
incompatible firmware will be displayed in red. To update a connected Controller's firmware see
Managing project TPCs and MSCs
If you will use a different type of Controller for your project, such as a TPC for a touch screen interface or an MSC
X for a high DMX channel count, or more than one Controller if the installation is large or distributed, then you will
- 141 -
