Unison Mosaic Designer User Manual
DALI Ballast Error
RIO D, TPC with TPC-RIO or DALI-S Expansion Module required.
Use this to trigger from a DALI ballast reporting an error. Specify the interface then use All to match if any ballast
on that interface reports an error. Alternatively select a single address to match to. Next select the error type to
match to.
DALI Input
RIO D, TPC with TPC-RIO or DALI-S Expansion Module required.
To use an MSC with a DALI-S expansion module as the input source, use the Controller setting to specify which
Controller has the expansion module and leave the Device as Local. If two DALI-S modules are connected, set
the port number to match which module should be the input source.
To use a TPC with TPC-RIO as the input source, use the Controller setting to specify which Controller has the
TPC-RIO and leave the Device as Local.
To trigger from a RIO D, set Device to RIO D and select the number of the RIO D, or leave this set to Any to
cause the trigger to attempt to match against DALI input from any RIO D. In this case, the RIO D number will be
captured as
variable .
The RIO D, TPC with TPC-RIO and DALI-S Expansion Module snoop the DALI bus and so the trigger can be set
up to respond to any DALI commands:
l
Command - select Direct Level (0>254), Scene or Relative Level
l
Address - select All, Group (0>15) or Ballast (1>64)
l
Min/Max - select the level to match for Direct Level triggering or
l
Scene - select the scene (1>16) for Scene matching or
l
Type - select the type of Relative Level command to match
The RIO D and TPC-RIO both recognise DALI input from Light Sensors and Occupancy Sensors that utilise
eDALI. When triggering from an Occupancy Sensor select which state is to be matched. When using a Light
Sensor, specify what range of light level (0>254) is to be matched. See the table below for light levels:
Light Sensor Level Lux Range
0 - 31 0.00 - 7.75
32 - 63 8.00 - 15.75
64 - 95 16.00 - 31.75
96 - 127 32.00 - 63.75
128 - 159 64.00 - 127.75
160 - 191 128.00 - 255.75
192 - 223 256.00 - 511.75
224 - 254 512.00 - 1008.00
DALI Bus Power
RIO D or TPC with TPC-RIO required.
- 108 -
