Firewall Service 539
Reviewing IP Filter Rules
To review the rules currently defined for your server, use the Terminal application to submit
the ipfw show command. The show command displays four columns of information:
When you type:
ipfw show
You see information similar to this:
0010 260 32688 allow log ip from any to any via lo*
0020 0 0 deny log ip from 127.0.0.0/8 to any in
0020 0 0 deny log ip from any to 127.0.0.0/8 in
0030 0 0 deny log ip from 224.0.0.0/3 to any in
0040 0 0 deny log tcp from any to 224.0.0.0/3 in
00100 1 52 allow log tcp from 111.222.33.3
to 111.222.31.3 660 in
...
Creating IP Filter Rules
To create new rules, use the ipfw add command. The following example defines rule 200, a
filter that prevents TCP packets from a client with IP address 10.123.123.123 from accessing
port 80 of the system with IP address 17.123.123.123:
ipfw add 200 deny tcp from 10.123.123.123 to 17.123.123.123 80
Deleting IP Filter Rules
To delete a rule, use the ipfw delete command. This example deletes rule 200:
ipfw delete 200
63500 Allowing user-specified TCP and UDP packets to access ports needed for
NetInfo shared domains. You can configure NetInfo to use a static port or to
dynamically select a port from 600 through 1023. Then use the Configure
Firewall window to allow all or specific clients to access those ports.
64000–65000 User-defined filters for Any Port.
Rule number Used by Firewall module for
Column Information
1 The rule number. The lower the number, the higher the priority of the rule.
2 The number of times the filter has been applied since it was defined
3 The number of bytes to which the filter has been applied
4 A description of the rule
