84
Using the Web Server
NOTE: The receiver has been designed to offer two
separate and independent differential data outputs. Each
one can output a specific type of differential message. If
only one output is used, select
Port=“None” for the other
output.
• Click on the Configure button to let the Web Server load all
your new parameters to the receiver.
• If the external radio used is a standalone, radio
transmitter, skip this step. But if an ARF7474x license-
free radio is used, click on the
Connections - Radio
submenu and from the Type field located in the External
Radio pane, select the type of license free radio used.
Then click on the
Configure button. You have now reached
the end of the configuration phase.
Ethernet Data
Streaming
Typically a base can be configured to deliver real-time
corrections to whoever asks for them through an IP
connection. This is achieved through the receiver’s Ethernet
port Ix.
The receiver is fitted with nine independent data outputs,
with the possibility for the administrator to define a specific
data format for each output.
In addition, for each data output, the administrator can
choose whether the base will be the server or the client in the
IP connection.
As a server (typical application), it will deliver its data to any
client asking for it and authorized to do so. Dozens of
different users can be connected on the same port.
As a client (more specific), the base will start delivering its
data after it has been able to establish a communication with
the specified IP address.
Follow the instructions below:
• Click on Base Setup > Data Streaming on IP and define the
general parameters of the base, as explained in section
ProFlex 800
RTK Corrections
Ethernet
Ports I1-I9
Internet (Server)
Users
