Using the Web Server

authentication (e.g. SpiderNet). In that case, the
message “$GPUID,, will be
generated automatically and sent to the server when
clicking on

Configure

Enable

Connect Now to allow the receiver to establish

the connection right after you have clicked on
Configure.

• At the bottom of the page, in the

Differential Port pane,

select the

Automatic option to let the receiver detect the

incoming differential stream automatically.

NOTE:

Automatic is the recommended choice for the

Differential Port setting because in this case, you don’t
need to define the ports receiving the two possible
differential streams.

• Click on the

Configure button to let the Web Server load all

your new parameters to the receiver. You just have now to
define the output messages (see Defining Output
Messages on page 64).

NTRIP Client Via

Modem

The internal modem should be configured first:

• Click on the

Connections menu and then on the Bluetooth/

Modem sub-menu.

• Set the following parameters in the

Internal Modem/Device

Settings pane:
–

Power: Select “On”. Then choose whether the modem
should be turned on automatically or manually:
Automatic: The modem will be switched on or off
automatically when the rover is respectively turned on
or off.
Manual: The modem will be powered up only by going
through the

Connections > Bluetooth/Modem page and

setting the modem to “Power On” (or using the
$PASHS,MDM,ON command).

–

Automatic Connection: Check this option.

Modem

RTK Corrections

ProFlex 800

NTRIP Caster

(Mobile Wireless
Communication)

Internet

IP address
or server name

(Client)
