Set Command Library

Comments

The command will be NAKed if the receiver has not been told
the radio is on the port specified by command
$PASHS,RDP,TYP.

Air link speed.
For PDL:
• 4800: 4800 Bd, GMSK modulation
• 9600: 9600 Bd, GMSK or four-level FSK

modulation

• 19200: 19200 Bd, four-level FSK modula-

tion

For MDL: 4800, 7600 or 9600
For ADL, 12.5 kHz:
• 4800 (GMSK modulation)
• 8000 (GMSK modulation)
• 9600 (4FSK modulation)

For ADL, 25 kHz:
• 4800 (GMSK modulation)
• 9600 (GMSK modulation)
• 16000 (GMSK modulation)
• 19200 (4FSK modulation)

4800, 7600, 8000,
9600, 16000,
19200

Radio sensitivity (PDL, ADL and MDL only)

LOW, MED, HIG,
OFF

Scrambler (PDL and ADL only):
• 0: Off
• 1: On

0, 1

Forward Error Correction (PDL and ADL only):
• 0: FEC Off
• 1: Hamming FEC On

0,1

s10

RF output power:
• 0: 100 mW
• 1: 500 mW
• 2: 1 W
• 3: 2 W
• 4: 4 W

Different meaning for 0-4 in ADL Vantage Pro:
• 0: Level 1 (2 W)
• 1: Level 2
• 2: Level 3
• 3: Level 4
• 4: Level 5

Use $PASHQ,RDP,PWR to read the real
power (in W) for each level)

0, 1, 2 (ADL Foun-
dation)
0-4 (ADL Vantage
and ADL Vantage
Pro)

*cc

Optional checksum

*00-*FF

Parameter

Description

Range
