Spectra Precision T41 User Manual
Data collector

FEATURES
• Processor: 1 GHz, Texas Instruments DM3730
• RAM: 512 MB
• Flash Storage: 16 GB
• 4.3" WVGA sunlight-readable Gorilla glass display
• Light sensor to auto-adjust display brightness
• Capacitive interface
• Integrated 3.75G cellular data, text and voice capability
• 8 megapixel camera with geo-tagging and dual LED
flash
• Bluetooth
®
2.1 with enhanced data rate
• Wi-Fi (802.11 b/g/n)
• GPS receiver, 2– 4 m accuracy (WAAS/SBAS capable)
• MCX port for optional external GPS antenna
• Electronic compass
• Accelerometer
• Robust custom port with USB 2.0 full speed protocol
• Conversion cables available for 9-pin serial or USB host
• MicroSD memory card slot (supports SDHC up to
32 GB)
• Integrated speaker and microphone
• 3.5 mm headset jack with audio capability
OPERATING SYSTEMS
• Windows Embedded Handheld 6.5
• Language support: Chinese (Simplified), English,
French, German, Italian, Japanese, Korean,
Portuguese, Russian or Spanish
Windows Embedded Handheld 6.5
Standard Software:
• SatViewer (GPS interface application)
• CellStart (WWAN configuration application)
• Microsoft
®
Office Mobile
®
2010 (Word Mobile, Excel
Mobile, PowerPoint Mobile, Outlook Mobile)
• Internet Explorer Mobile 6
• Microsoft My Phone with SMS text messaging
• Camera control application
• Flashlight mode control application
• Calculator
• Calendar
• Microsoft Pictures & Videos
• Windows Media
®
Player
• Windows Live Messenger
• Microsoft Task Manager & Notes
• Adobe Reader LE 2.5
STANDARD ACCESSORIES
• International AC charging kit
• T41 USB cable
• Wrist strap
• Ultra clear screen protectors (qty 2) kit
• Quick Start Guide
OPTIONAL ACCESSORIES
• 9-pin serial adapter
• USB host adapter
• Capacitive stylus with tether
• External battery pack
• Port cover
• Ultra clear screen protectors (qty 10) kit
• Anti-reflective screen protectors (qty 2) kit
• Vehicle charging kit
• Capacitive touchscreen gloves
• External GPS antenna
ENVIRONMENTAL SPECIFICATIONS
Water . . . . . . . . . . . .Survives driving rain and water spray
IEC-60529 IPx5, water jet 12.5 mm dia @ 2.5–3 m
Dust . . . . . . . . . .Protected against dust, IEC-60529 IP6x,
dust chamber with under-pressure
Drops . . . . . . . . . Survives multiple drops of 4 ft (1.22 m),
MIL-STD-810G, Method 516.6, Procedure IV, Transit Drop
Operating Temperature . . . . . . . . . . . . . –22 ºF to 144 ºF
(–30 ºC to 60 ºC), MILSTD-810G, Method 502.5,
Procedure I, II, III (Low Temp Operating –30 ºC);
Method 501.5, Procedure I & II
(High Temp Operating 60 ºC)
Storage Temperature . . . . . . . . . . . . . . . – 40 ºF to 158 ºF
(– 40 ºC to 70 ºC), MILSTD-810G, Method 502.5,
Procedure I, II, III (Low Temp Storage – 40 ºC);
Method 501.5, Procedure I & II
(High Temp Storage 70 ºC)
Temperature Shock . . Cycles between – 22 ºF and 144 ºF
(– 30 ºC and 60 ºC),MIL-STD-810G,
Method 503.5, Procedure I-C
Humidity . . . . . .90% relative humidity with temperatures
between 22 ºF and 144 ºF (30 ºC and 60 ºC),
MIL-STD-810G, Method 507.5, Procedure II
Altitude . . . . . . . . . . .15,000 ft (4,572 m) at 73 °F (23 ºC)
to 40,000 ft (12,192 m) at –22 °F (–30 ºC),
MIL-STD-810G, Method 500.5, Procedure I, II & III
Vibration . . . . . . . . . . . . . . General minimum integrity and
loose cargo tests, MILSTD-810G, Method 514.6,
Procedure I & II, Category 5
Solar Exposure . . . . . . Survives prolonged UVB exposure,
MIL-STD-810G, Method 505.5, Procedure II
Chemical Exposure . . . . . . Resistant to mild alkaline and
acid cleaning solutions, fuel hydrocarbons, alcohols
and common vehicle and factory machine lubricants
PHYSICAL
Size . . . . . . . . . . . . . . . . . . . . . . . . . 6.1 in × 3.2 in × .9 in
(15.5 cm x 8.2 cm x 2.5 cm)
Weight . . . . . . . . . . . . . .13.5 oz (.4 kg), including battery
ELECTRICAL
Processor . . . . . . . . . . . 1 GHz, Texas Instruments DM3730
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 512 MB
Storage . . . . . . . . . . . . . . . . . . . . . . . . 16 GB, non-volatile
Expansion . . . . . . . . . . . microSD card slot, SIM card slot
Display . . . 4.3 in (10.9 cm), 480 x 800 pixel, WVGA TFT
Battery . . . . 3.7 V, 3.3 Ah, 12.2 Wh, Lithium-ion polymer
I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . .3.5mm audio jack;
Custom Port that supports USB 2.0 Host,
USB Client, 9-pin Serial and 5.6 V (5.0 V to 5.9 V)
DC input power
GPS Receiver . . . . . . . 2–4 m accuracy with WAAS/SBAS
correction; MCX port for optional external antenna
Radios . . . . . . . .Bluetooth 2.1 +EDR; Wi-Fi 802.11 b/g/n
WWAN radios . . . . . . . . . . . . . . . . . . . . . . UMTS / HSPA+,
GSM / GPRS/ EDGE, UMTS
Bands (WCDMA/FDD) . . . . . . . . . . . . . . . . . . .800, 850, 1900,
AWS and 2100 MHz
GSM Bands . . . . . . . . . . . . . 850, 900, 1800, 1900 MHz
CERTIFICATIONS
WFCC, CE, R&TTE, IC (Canada), C-tick, GCF compliant,
RoHS compliant, Section 508 compliant, PTCRB,
SAR, AT&T network compatible, Wi-Fi Alliance certified,
CCX, USB 2.0 Full Speed, MIL-STD-810G, IP65,
MIL-STD-461E.
