117
Web Server Help Files Collection
Current values of tiltmeter data:
For each serial port (A, B, F), the following parameters are
returned:
Legacy D-File Support:
Data Output
This section consists of three pages, each of them listing a
category of output data delivered by the receiver.
Differential Messages:
Parameter
Designation
$PASHQ
Angular Displacement
North
Current value of angular displacement
(North), as delivered by the tiltmeter.
XDR
Angular displacement
East
Current value of angular displacement
(East) as delivered by the tiltmeter.
XDR
Temperature
Current value of temperature, as
delivered by the tiltmeter.
XDR
Parameter
Designation
$PASHQ
Process tiltmeter
Tells whether the receiver is allowed
to query the tiltmeter, if connected to
this port.
TLT
Baud Rate
Current value of baud rate used on
the port
PRT
Mode
Indicates whether the port is currently
an RS232 (232) or RS422 (422) serial
port. Only port A can be RS422 or
RS232. All the others are necessarily
RS232.
MDP
RTS/CTS
Indicates whether the handshaking
protocol is used (Enabled) or not (Dis-
abled) on this port.
CTS
Initialization String
String used by the receiver to initialize
the tiltmeter, if connected to this port.
TLT
Trigger String
String used by the receiver to query
the tiltmeter, if connected to this port.
TLT
Interval
Current value of time interval, in sec-
onds, used by the receiver to query
the tiltmeter, if connected to this port.
TLT
Parameter
Designation
$PASHQ
Legacy D-File Support
Indicates whether the legacy D-file is
supported (Yes) or not (No). In the lat-
ter case, only the G-file is supported.
RFT
