Laser Levels
Grade & Universal Lasers
Horizontal &
Vertical Lasers
LL100
LL300
LL400
LL500
GL412/512
GL422/522
UL633
HV101
HV301/301G
Laser type /
classification
650 nm visible,
Class 2
635 - 670 nm
visible,
Class 2
650 nm visible,
Class 2
670 nm,
Class 2
650 nm,
Class 2,
3 mW
650 nm,
Class 3A/3R,
<5 mW
650 nm,
Class 3A/3R,
<5mW
635 nm,
Class 3A/3R,
<5 mW
635 nm / 532 nm
Class 3A/3R,
<5 mW
Self-leveling
range
±5 degrees
electronic servo
self-leveling
±5 degrees
electronic servo
self-leveling
±5 degrees
electronic servo
self-leveling
±11 minutes
wire hung
compensator
±5 degrees
electronic servo
self-leveling
±5 degrees
electronic servo
self-leveling
±14 degrees
electronic
servo self-
leveling
±5 degrees
electronic
servo self-
leveling
±5 degrees
electronic servo
self-leveling
Out-of-level
indication
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Power source
2 x D-cell
Alkaline
4 × D-cell
Alkaline
standard,
recharge
optional
4 x D-cell
Alkaline
standard,
niMH optional
4 × D-cell
Alkaline
standard,
recharge
optional
4 x D-cell
niMH
standard,
Alkaline
backup
4 x D-cell
niMH
standard,
Alkaline
backup
4 x D Cell,
niMH pack
standard,
Alkaline
backup
2 x D-cell
Alkaline
4 × D-cell
recharge
batteries, Alkaline
backup
Battery life
80 hr Alkaline
90 hr Alkaline,
45 hr niMH
90 hr Alkaline,
55 hr niMH
175 hr Alkaline,
100 hr niMH
75 hr ni-Cad
90 hr Alkaline,
28 / 55 hr
niMH
90 hr Alkaline,
28 / 55 hr
niMH
40 hr alkaline,
35 hr niMH
50 hr
Alkaline
90 /45 hr Alk,
40 / 18 hr
Rechargeable
Grade Capability
Manual -
Single axis
Manual -
Single axis
Manual -
Single axis
no
electronic
-10 to +15%
Single Axis
electronic
-10 to +15%
Dual Axes
electronic
-25% to +25%
X, Y, Z Axis
Manual -
Single axis
Manual -
Single axis
Warranty
3 Years
2 Years
2 Years
2 Years
2 Years
2 Years
5 Years
3 Years
2 Years
Laser Pointers, Line Generator, and Handheld Distance Measuring Devices
LP30
LP50
5.2XL
1.3XL
1.5PL
HD100
QM75
Self-leveling
Yes
Yes
Yes
Yes
+/- 3°
n/A
n/A
Working range - Visible
100 ft (30 m)
100 ft (30 m)
100 ft (30 m)
100 ft (30 m)
100 ft (30 m)
330 ft (100 m)
230 ft (70 m)
With Receiver
n/A
n/A
250 ft (75 m)
250 ft (75 m)
250 ft (75 m)
n/A
n/A
Accuracy
+/- 1/16 in at 17 ft
1.5 mm @ 5 m
+/- 1/16 in at 17 ft
1.5 mm @ 5 m
+/- 1/16 in at 17 ft
1.5 mm @ 5 m
+/- 1/16 in at 17 ft
1.5 mm @ 5 m
+/- 1/32 in @ 17 ft
1.0 mm @ 5m
+/-1/16 in
1.5 mm
+/- 1/16 in
1.5 mm
Warranty
3 Years
3 Years
3 Years
3 Years
1 Year
3 Years
3 Years
Optical Auto Levels
AL20M
AL24A
AL24M
AL28A
AL28M / AL28M-G
AL32A
Magnification
20x
24Ч
24Ч
28Ч
28Ч
32x
Accuracy
+/- 2.5 mm (0.10 in)*
±2.0 mm (0.08 in)*
±2.0 mm (0.08 in)*
±1.5 mm (0.06 in)*
±1.5 mm (0.06 in)*
±1.0 mm (0.04 in)*
Aperture
30 mm (1.2 in)
30 mm (1.2 in)
30 mm (1.2 in)
30 mm (1.2 in)
30 mm (1.2 in)
36 mm (1.4 in.)
Shortest focus
0.6 m (1.97 ft)
0.6 m (1.97 ft)
0.6 m (1.97 ft)
0.6 m (1.97 ft)
0.6 m (1.97 ft)
0.6 m (1.97 ft)
Compensator
Magnetic dampened
Air dampened
Magnetic dampened
Air dampened
Magnetic dampened
Air dampened
*note: Standard deviation according to Din 18723 on one kilometer of double leveling
AL28M-G available in gon
© 2005-2012, trimble navigation Limited. All rights reserved.
trimble, the Globe & triangle logo, and Spectra precision are
trademarks of trimble navigation Limited registered in the United
States patent and trademark Office and other countries. All other
trademarks are the property of their respective owners.
pn 022485-175L (04/12)
Contact Information:
TRIMBLe / SPeCTRA PReCISIOn DIVISIOn
8261 State Route 235
Dayton, Ohio 45424-6383 U.S.A.
(888) 527-3771 (toll Free in U.S.A.)
+1-937-203-4419 phone
+1-937-482-0030 Fax
www.trimble.com/spectra
eUROPe
trimble Kaiserslautern GmbH
Am Sportplatz 5
67661 Kaiserslautern
GeRMAnY
tel +49-(0)6301-71 14 14
Fax +49-06301-32213
n
Toughest on earth
n
Strongest Warranty
n
easiest to Use
Construction Productivity Tools
Model
Horizontal Accuracy
Diameter Range
Application
Laser Levels
1/8 in @ 100 ft
(3.0 mm @ 30 m)
1,000 ft
(300 m)
■
■
Forms, footings and foundations (residential jobs)
■
■
Septic tank or swimming pool installations
■
■
estimating cut and fill
■
■
Decks and terraces
3/32 in @ 100 ft
(2.2 mm @ 30 m)
1,300 ft
(400 m)
■
■
elevation control across small- and mid-size construction sites
■
■
excavations
■
■
Basic slopes
■
■
Leveling forms and footers
■
■
Concrete pours
■
■
1 m (4 ft) marks
1/16 in @ 100 ft
(1.5 mm @ 30 m)
2,600 ft
(800 m)
■
■
Checking/setting elevations, concrete forms, footings, and foundations for
large commercial jobs
■
■
Basic slope work such as foundations for small-to-large site prep work
■
■
excavating for forms or footers with CR600 receiver
■
■
Sub-base leveling with skid steer loaders and CR600 receiver
■
■
Long range machine control applications
1/16 in @ 100 ft
(1.5 mm @ 30 m)
1,600 ft
(500 m)
■
■
Checking elevations
■
■
Setting concrete forms, footings, and foundations (small-to-large jobs)
■
■
ideal for larger pads
■
■
Machine control compatible
Grade & Universal Lasers
1/16 in @ 100 ft
(1.5 mm @ 30 m)
2000 / 2600 ft
(600 / 800 m)
■
■
Leveling concrete forms and footers
■
■
Vertical alignment and plumb such as anchor bolt and form alignment
■
■
Single and dual slope grading and excavating applications
■
■
Grading sports fields, tennis courts and driveways
1/16 in @ 100 ft
(1.5 mm @ 30 m)
2000 / 2600 ft
(600 / 800 m)
■
■
Steep slope road embankments and ditch banks
■
■
High accuracy grade work
■
■
Wireless remote monitoring with HL750
■
■
Single and dual slope grading and excavating applications
1/16 in @ 100 ft
(1.5 mm @ 30 m)
2600 ft
(800 m)
■
■
Dual slope grading and steep slope excavating
■
■
precision grade up to 25% in X, Y and Z axis
■
■
Drift free vertical alignment and plumb
■
■
pipe and drainage installations, measuring slopes in existing pipes
Horizontal & Vertical Lasers
1/8 in @ 100 ft
(3 mm @ 30 m)
Receiver: 1000 ft
(300 m)
Visible: 200 ft (60 m)
■
■
interior and exterior light commercial and residential construction
■
■
Leveling and aligning of interior walls and ceilings
■
■
exterior elevation checking and interior finishing work
3/32 in @ 100 ft
(2.2 mm @ 30 m)
Receiver: 1600 ft
(500 m)
Visible: 330 ft (100 m)
/ 500 ft (150 m)
■
■
interior and exterior light to medium commercial and residential projects
■
■
HV301G Green beam for extended ranges or bright light conditions
■
■
Leveling and aligning walls, ceilings, and raised floors
■
■
interior finishing work
LL100
LL300
LL400
LL500
GL412/GL422
GL512/GL522
UL633
HV101
HV301/HV301G
Productivity Is The Right Tool For The Job...
From The Deepest Tool Box In The Laser Business.
The Broadest Line From
the Strongest Name in Lasers
An entire industry. Invented here.
there’s a reason Spectra precision is the strongest name in
the industry. We invented the industry. From day one, we
have pioneered every major development in laser positioning
for construction. that’s why you’ll find over one million of our
professional rotating lasers on job sites around the world...
more than any other brand.
easiest to Use
Spectra precision instruments are engineered with state-of-
the-art components, giving you the most dependable, easiest
to use, laser on the job site. Spectra precision products are
always ready to work when you are.
Best Support
each Spectra precision product is built with the user in
mind. that is why we test and retest every laser we
manufacture to assure you the most dependable, accurate
laser in the world. Backed by the world’s largest network of
repair centers, Spectra precision is unmatched for service,
support and dependability.
