QM75 Quick Measure
Laser Distance Meter
The Rugged Laser Distance Meters
Drop With No Risk
© 2012, Trimble Navigation Limited. All rights reserved. Trimble,
the Globe & Triangle logo and Spectra Precision are trademarks
of Trimble Navigation Limited, registered in the United States
Patent and Trademark office and in other countries. All other
trademarks are the property of their respective owners.
PN 022507-285A (09/12)
Contact Information:
NORTH AMERICA
Trimble Spectra Precision Division
8261 State Route 235
Dayton, Ohio 45424 U.S.A.
Toll Free +1-888-272-2433
Fax +1-937-482-0030
www.spectra-productivity.com
EUROPE
Trimble Kaiserslautern GmbH
Am Sportplatz 5
67661 Kaiserslautern
GeRmANy
Phone +49-6301-711414
Fax +49-6301-32213
Spectra Precision QM
Specification
QM55
QM75
QM95
Range
50 m (165 ft)
70 m (230 feet)
200 m (650 feet)
Accuracy
± 1.5 mm
(± 1/16 in)
± 1.5 mm
(± 1/16 in)
± 1.0 mm
(± 1/24 in)
Units of Measure
m, ft, in, ft-in
m, mm, ft, in, yds
m, mm, ft, in, yds
Automatic Shut Off
3 minutes
10 minutes
10 minutes
Battery Life
5000+ measures
8000 measures
8000 measures
Power Supply
2 x AAA 1.5V
2 x AAA 1.5V
2 x AA 1.5V
Power Indication
LCD 3 segments
LCD 4 segments
LCD 4 segments
Drop Performance
1.5 m (5 ft)
1.5 m (5 ft)
1.5 m (5 ft)
Dust & Water
Resistance
IP54
IP55
IP54
Laser Type / Power
635nm visible red /
< 1 mW
635nm visible red /
< 1 mW
635nm visible red /
< 1 mW
Dimensions
52 x 28 x 125 mm
(2.0 x 1.1 x 4.9 in)
34 x 42 x 125 mm
(1.3 x 1.6 x 4.9 in)
62 x 28 x 120 mm
(2.4 x 1.2 x 4.7 in)
Weight with
Batteries
187 g (6.6 oz)
144 g (5.1 oz)
217 g (7.7 oz)
Warranty
3 Years
3 Years
3 Years
Functions
QM55
QM75
QM95
Usage
Indoor
Indoor / Outdoor
Indoor / Outdoor
Single Measure
Continuous Measure
Add / Subtract
Side Measure
Button
Extension Tab
Auto Detected
The Qm Quick measure laser distance meters are the
first family of distance meters designed specifically
for the tough construction site environment.
The housing are made of durable engineered plastic
with extensive use of protective rubber overmold.
The electronics have been cleverly isolated resulting
in a product that survives a drop and the typical
rough conditions found on jobsites.
Measure Difficult to Reach Areas including
Restricted Areas and Over Water
QM Quick Measure
Laser Distance Meters
