131
Web Server Help Files Collection
(ports A, B, F), set their parameters as explained in the table
below.
Network 1
Use this area to declare the type of connection used by the
base to distribute its data through a mobile communication
Parameter Designation $PASHS
Connection
Choose the device to which the port is connected. The
possible choices are:
• None/Cable: The port is not used or is connected to
an external device via a cable.
• U-Link TRx (on port A only): The port is connected
to a U-Link TRx.
• Magellan UHF (on port A only): The port is con-
nected to transmitter P/N 800986-x0.
• PDL HPB/LBP: The port is connected to a PDL
transmitter.
• ARF7474B EU: The port is connected to a license-
free radio for use in European countries.
• ARF7474A NA: The port is connected to a license-
free radio for use on the North American continent.
• ADL Vantage/Vantage Pro: The port is connected
to an ADL transmitter.
• XDL Rover: The port is connected to an external
receiver (PacCrest XLD Rover model)
RDP,TYP
(+ ECP)
Baud Rate
Choose a baud rate from the list. The selected rate
will be used by the port.
PRT
Mode
Port A only. Specify the type of serial link (“RS232 or
“RS422”) for Port A.
MDP
RTS/CTS
Check this button to enable the RTS/CTS handshak-
ing protocol on the port (if 232). Clear it otherwise.
CTS
