RTK Configuration Steps
Embedded
Transceiver (ADL
Foundation)
RTK Rover Setup
Prerequisites • Insert a freshly charged battery into the ProFlex 800.
• Use a range pole fitted with a 5/8” male adaptor at the
upper end (not provided).
• Mount the GNSS antenna at the top of the range pole.
ProFlex 800
Base
Cable P/N 802143
To
GNSS
Antenna
P
o
w
er
GNSS Input
External 9-36 V
DC Power Source
Fuse (4 A)
+
Radio
Antenna
ProFlex 800
Base
To
GNSS
Antenna
P
o
rt
A
GNSS Input
Radio
Antenna
(Radiated power
limited to 100 mW)
(No power
limitation)
External Battery Used
Internal Battery Used
