610
Query Command Library
c6
Protocol used:
PDL:
• 0: Transparent
• 1: TRIMTALK
• 2: DSNP
MDL:
• 0: Transparent
• 1: Not used
• 2: DSNP
ADL, XDL:
• 0: Transparent (with EOT time out)
• 1: TrimTalk 450S
• 2: Not used
• 3: SATEL
• 4: TrimMarkII/IIe
• 5: TT450S (HW)
• 6: TRIMMARK3
• 7: Transparent FST
• 8: U-Link (ADL only)
0-7
c7
Air link speed
For PDL:
• 4800: 4800 Bd, GMSK modulation
• 9600: 9600 Bd, GMSK or four-level FSK
modulation
• 19200: 19200 Bd, four-level FSK modula-
tion
For MDL: 4800, 7600 or 9600
For ADL, 12.5 kHz:
• 4800 (GMSK modulation)
• 8000 (GMSK modulation)
• 9600 (4FSK modulation)
For ADL, 25 kHz:
• 4800 (GMSK modulation)
• 9600 (GMSK modulation)
• 16000 (GMSK modulation)
• 19200 (4FSK modulation)
4800, 7600, 8000,
9600, 16000,
19200
s8
Radio sensitivity (for PDL, ADL, XDL and
MDL)
LOW, MED, HIG,
OFF
f9
Receive frequency, in MHz
410-470
f10
Transmit frequency, in MHz
410-470
c11
Channel spacing, in kHz:
• MGL, XDL and MDL: 12.5 only
• PDL: 12.5 or 25
• ADL: 12.5 or 25
12.5, 25
s12
RF band, in MHz (for PDL and ADL only)
410-430, 430-450,
450-470
Parameter
Description
Range
