Page 76

Using the Web Server

• At the bottom of the page, in the

Differential Port pane,

select the

Automatic option to let the receiver detect the

incoming differential stream automatically.

NOTE:

Automatic is the recommended choice for the

Differential Port setting because in this case, you don’t
need to define the ports receiving the two possible
differential streams.

• Click on the

Configure button to let the Web Server load all

your new parameters to the receiver. You just have now to
define the output messages (see Defining Output
Messages on page 64).

RTK Corrections

Received on Port

A, B or F

• Unless already done, please follow all the steps described

in section General Parameters on page 49 before
proceeding with the steps below.

• Still on the

Rover Setup page, in the Serial Port x pane

corresponding to the port you want the receiver to use (A,
B or F), set the following parameters:

–

Connection: Choose the name of the corrections
receiver device connected to the port. As a general
rule, choose “None/Cable” for any external corrections
receiver connected to that port. But if the device used
is a license-free radio, type ARF7474B EU or
ARF7474A NA, choose specifically this type of radio.

– Port settings (

Baud Rate, Mode, RTS/CTS): Set the serial

port to match the external device connected to it.
Setting these fields will update the corresponding
fields on the

Serial Ports sub-menu page
