102
Web Server Help Files Collection
Antenna
Recording and Output
Elevation Mask Angle value in degrees (0-90). Rele-
vant to raw data recording and output.
ELM
Heading
Heading mode currently used (exter-
nal or off)
CPD
With Heading Mode acti-
vated (external):
Heading Port
Port used to route data from the exter-
nal GNSS receiver to your receiver.
CPD
Azimuth Offset Azimuth offset in degrees CPD
Elevation Offset Elevation offset in degrees CPD
Maximum Baseline Eleva-
tion
In degrees CPD
Maximum Baseline
Length Error
In meters CPD
Parameter Designation $PASHQ
Receiver Antenna
Name of the GNSS antenna connected to
the coaxial connector marked with a satellite
icon (located on the receiver rear panel); a
case-sensitive parameter (31 characters
max.)
ANP,OWN
Reference Position
Refers to the antenna reduction mode. Indi-
cates the physical location for which the
receiver computes a position. This can be
the antenna phase center, the ARP
(Antenna Reference Point) or the ground
mark.
ANR
Antenna Height Height above the ground, in meters. ANH
Measurement Type
“Vertical” or “Slant”.
“Vertical” is the general case, “Slant” is used
when the GNSS antenna is mounted on a
tripod.
ANH
Antenna Radius
Horizontal distance, in meters, from the geo-
metrical center to the edge of the antenna
used.
ANT
SHMP Offset
Antenna parameter describing the vertical
offset of the Slant Height Measurement
Point, measured from the ARP, in meters.
ANT
Virtual Antenna
Name of the virtual antenna used, if any.
“OFF” if no virtual antenna is used.
ANP
Parameter Designation $PASHQ
