Using the Web Server

• Now please follow all the steps described in section

General Parameters on page 49 and then proceed with the
steps below.

• Still on the

Rover Setup page, in the Network pane, set the

following parameters:

–

Connection: Choose “Modem Direct IP - Port E”. As a
result, new fields appear in this pane that you should
set as instructed below:

–

The rover being a client, enter the information (

Connect

Now, Address, Port, Login, Password) allowing it to
connect to the base (the server) from which it is
supposed to receive corrections. The login and
passwords are required only if the server demands
authentication (e.g. SpiderNet). In that case, the
message “$GPUID,, will be
generated automatically and sent to the server when
clicking on

Configure.

Enable

Connect Now to allow the receiver to establish

the connection right after you have clicked on
Configure.

• At the bottom of the page, in the

Differential Port pane,

select the

Automatic option to let the receiver detect the

incoming differential stream automatically.

NOTE:

Automatic is the recommended choice for the

Differential Port setting because in this case, you don’t
need to define the ports receiving the two possible
differential streams.

• Click on the

Configure button to let the Web Server load all

your new parameters to the receiver. You just have now to
define the output messages (see Defining Output
Messages on page 64).

Direct IP Via

Ethernet

• First, click on the

Connections> Ethernet submenu.

• Set the following Ethernet parameters to allow the receiver

to access the network through its Ethernet port:

RTK Corrections

Ethernet

ProFlex 800

Base

IP address
or server name

(Client)

Internet
