612
Query Command Library
Examples
If an internal PDL radio receiver is used:
$PASHQ,RDP,PAR,D
$PASHR,RDP,PAR,D,PDL,ON,0,AUT,0,4800,MED,444.5500,446.7750,12.5,4
30-450,V02.58,,0,0*03
If an internal U-Link Rx is used:
$PASHQ,RDP,PAR,D
$PASHR,RDP,PAR,D,MDL,ON,4,AUT,0,9600,MED,447.1000,447.1000,12.5,,
V01.00,445.5500*20
If an external radio transmitter P/N 800986 is used:
$PASHQ,RDP,PAR,D
$PASHR,RDP,PAR,D,MGL,,1,,,,,0.0000,447.1000,,,TD20-EUHFV10300*01
Comments The command will be NAKed if the receiver has not been told
the radio is on the specified port using command
$PASHS,RDP,TYP.
Relevant Set
Command
$PASHS,RDP,PAR
See also $PASHS,RDP,TYP
d21
Current output power (index)(ADL only):
• ADL Foundation:
– 0: 100 mW
– 1: 500 mW
– 2: 1 W
• ADL Vantage:
– 0: 100 mW
– 1: 500 mW
– 2: 1 W
– 3: 2 W
– 4: 4 W
• ADL Vantage Pro:
– 0: Level 1 (2 W)
– 1: Level 2
– 2: Level 3
– 3: Level 4
– 4: Level 5
See command $PASHQ,RDP,PWR to read
the current power setting (expressed in Watts)
0-4
*cc Checksum *00-*FF
Parameter Description Range
