Teledyne LeCroy Corporation Tool Bar
88 USB Protocol Suite User Manual
USB 2.0 USB 3.0 Show
Hiding Traffic (2.0 & 3.0)
You can Hide Devices and NAK’s NRDY’s by clicking the buttons in the table below or from
the View menu. Click View and select Hide Devices (Addr/Endp)... as shown in
Figure 4.2
on page 88 .
Figure 4.2: Selecting Hide Devices
Show USB 2.0 traffic only. Display USB 3.0 traffic only.
Hide Devices Hide NAK’s/NRDY’s.
Hide All Packets Except
Transfers Packets
