Teledyne LeCroy Corporation Spreadsheet View
144 USB Protocol Suite User Manual
5.37.1 Columns
To add a column, right‐click a column header, select Add Column, and then select the
column name. You can also add a column by dragging the attribute field
(in the left column) from the Detail View into the Spreadsheet View.
To delete a column, right‐click a column header and then select Remove Column.
To reposition a column, drag the column header to the new position.
To resize columns, select the column divider and drag the divider to the right or left.
5.37.2 Rows
To manipulate rows, right‐click the left‐most column gray area to display the following
commands:
Display Options Opens the Display Options menu 
(see
“Display Options” on page 175 ).
CATC Walk See and manage playlists.
(see
“CATC Walk Playlist” on page 117 ).
Real‐time Statistics Allows you to view traffic statistics as they occur.
See
“Real Time Monitoring” on page 253 .
USB 3.0 Electrical
Test Displays the USB3 Electrical Test dialog.
(see
“USB 3.0 Electrical Test Modes” on page 373 ).
Trace Views Displays CATC Trace, Compressed CATC Trace,
Spreadsheet (Color), or Spreadsheet (B/W).
Unhide cells Unhide previously hidden Traffic, VBus Power, or ALL
Zoom In Increases the size of the displayed elements.
Zoom Out Decreases the size of the displayed elements.
Wrap Wraps displayed packets within the window.
Show USB 2.0 Traffic
Only Displays only USB 2.0 traffic.
Show USB 3.0 Traffic
Only Displays only USB 3.0 traffic.
Hiding USB 2.0
Traffic Hides.
SOF’s: Start of Frames
NAK’s: NAK’ed Transactions
Devices: Packets belonging to specified devices by address and
endpoint
Chirps: Chirp‐K and Chirp‐J Bus conditions (these are recorded
only)
