USB Protocol Suite User Manual 303
Recording Rules ‐ USB 3.0 (Voyager/Advisor T3 only) Teledyne LeCroy Corporation
10.8.5 Assigning an Action
After you have dropped the Event button in a cell in the Main Display area, you can assign
an action to the event.
Note:
If you do not assign an action to an Event button, the analyzer ignores the event.
To assign an action to an Event button, see “Assigning an Action” on page 289 .
Note: You can also set actions within the Properties dialog for each event. Double‐click the Event
button to open the Properties dialog, then select the Actions tab and set your actions.
10.8.6 Recording Rules Pop-Up Menus
The Recording Rules window has context‐sensitive pop‐up menus that are associated with
the following types of object: cells, events, and actions.
Cell Pop-up Menu
If you click a cell in the Main Display area that has an Event button contained in it, the Cell
pop‐up menu appears. The Cell pop‐up menu has the following options.
 New Event: Displays the same menu that you get when you click the New Event
button on the toolbar.
 Properties: Displays the Properties dialog for the selected cell.
Event Pop-up Menu
If you click an Event button in the Main Display area, the Event pop‐up menu appears (see
“Event Pop‐up Menu” on page 291 ).
Action Pop-up Menu
If you click an Action button in the Main Display area, the Action pop‐up menu appears
(see
“Action Pop‐up Menu” on page 290 ):
Note: Recording Rules for USB 3.0 currently do not support more than two independent states. The
Advance Sequence option is not currently available for USB 3.0 recording rules.
10.8.7 Actions and Action Properties
For the available Actions and Action Properties, see “Recording Rules Actions and Action
Properties” on page 281 .
Action Properties
For the Action Properties, you can set Internal Triggering and External Triggering.
Recording Rules for USB 3.0 currently do not support more than two independent states.
The Advance Sequence option is not currently available for USB 3.0 recording rules.
