USB Protocol Suite User Manual 81
The Main Display Window Teledyne LeCroy Corporation
4.2.1 Exports to .CSV
.CSV files may be created as exports from the contents of 2.0 CATC Trace Packet and
Transaction Views, 3.0 CATC Trace Packet views, and any Spreadsheet view. The output is
limited to 1 million rows.
Export Packets to .CSV
When viewing 2.0 or 3.0 Packets in either the CATC Trace view or the CATC Trace
Compressed view, selecting Export > Packets to .CSV Spreadsheet item from the Export> menu in a graphic> exports the packets to a .csv file
in a pre‐configured format. The first row of that .csv file shows what each column
represents.
Export Transactions to .CSV
When viewing 2.0 Packets in either the CATC Trace view or the CATC Trace Compressed
view, selecting Export > Transactions to .CSV exports the 2.0 transactions to a .csv file in a
pre‐configured format. The first row of that .csv file shows what each column represents.
Export Spreadsheet View to .CSV
When viewing 2.0 Packets in either the Black and White or Colored Spreadsheet Views
Trace view, selecting Export > Spreadsheet to .CSV exports the contents of the
spreadsheet to a .csv file in a pre‐configured format. The columns match the columns as
you have defined them in your Spreadsheet view.
4.2.2 Exporting Packets to USB 2.0 Host Traffic Generator Text File (.utg files)
Before exporting to a .utg file, first make sure the .usb file contains traffic for only one
device:
1. Hide all other device addresses in the trace, leaving only the address of your device
and the Address 0 (the default enumeration address).
Check for Updates Use the Internet to analyze your system for licensed updates. You can
set the system to automatically check for updates at application
startup in the Teledyne LeCroy USB Protocol Suite Software Update
window.
See
“Software Updates” on page 388 .
Shortcut List Displays the Shortcuts List of navigation, common, search, decode
levels, and miscellaneous mouse and keyboard shortcuts. See
“Shortcut List” on page 396.
About USB
Protocol Suite Displays version information about the Voyager M3/M3i and the
USB Protocol
Suite.
See “Software, Firmware, and BusEngine Revisions” on page 387 .
Menus Functions
